RUCKUS ICX 7550-48F
Entry-Level Aggregation 48 Ports 1G/10G SFP/SFP+ Switch
$1.00
RUCKUS ICX 7550 Switches Features
The RUCKUS® ICX® 7550 switch family delivers enterprise-grade wired connectivity for Wi-Fi 6 access points at the network edge. Featuring 2.5/5/10 GbE multigigabit interfaces and next-gen 802.11bt 90W PoE, it provides the power, flexibility, and scale required for large campus networks.
Future-ready 40/100 GbE uplinks prevent congestion and guarantee seamless wireless performance in high-density areas.
With 8 stackable options, the ICX 7550 can be deployed across gigabit edges, multigigabit aggregation, and fiber-to-the-room scenarios, providing up to 2000W PoE budget and 90W per port.
Optimized wired base for Wi-Fi 6 device connectivity
Up to 3× 40/100 GbE uplinks and stacking options
High-density multigigabit and 1/10 GbE fiber connectivity
Powerful 90W PoE and total 2000W budget for devices
Supports RUCKUS Cloud, SmartZone, and Unleashed management
Automated configuration with Zero Touch Provisioning
Advanced monitoring via RUCKUS Analytics integration
Dual redundant, load-sharing power units
100G QSFP stacking up to 10 km and 12 units
ISSU for stack-level updates without downtime
Hot-swap stacking for operational continuity
IPv4 and IPv6 dual-stack support
Routing features: OSPF, BGP, VRRP, PIM, PBR, VRF
Unified automation with RUCKUS Cloud or SmartZone
48-port with 36-port 100/1000 Mbps SFP, 12-port 1/10 Gbps SFP+, 2x 40/100Gbps QSFP+ dual-mode uplink/stacking ports, modular slot. Power supplies, fans and port modules sold separately.
Switching capacity (data rate, full duplex):912 Gbps
Forwarding capacity (data rate, full duplex):678 Mpps
Maximum VLANs:4,095
Maximum PVLANs:256
Power inlet:C14 (AC), Dinkle 2EHDP-03P (DC)
Input voltage/frequency:AC: AC: 100 to 240 VAC @ 50 to 60 Hz | DC: 40 to 60 VDC
Power supply rated maximum output (AC)：2 x 400W
Power supply rated maximum output (DC):2 x 400W
Switch power consumption (25°C)：
10% traffic2 (no PoE load):81.3 W 100% traffic2 (full PoE load):166.8 W
Dimensions:
Height x Width x Depth(cm):4.40 x44 x40.64
Height x Width x Depth(inches):1.73x17.32x16
Net Weight:6.42 kg(14.15 lb)
